High-performance and flexible applications
The imageFORMULA DR-C240’s premium build quality and productivity-focused features are a breakthrough in this value segment. Offering rapid scanning at up to 45ppm/90ipm, the imageFORMULA DR-C240 is the natural all-round choice for office departments and workgroups. Its quiet operation – and compact, attractive desktop design – make a great impression in front offices and customer service points, for example in banks, hotels, hospitals and government offices.
Designed in response to customers’ needs
The imageFORMULA DR-C240’s robust construction and rugged document feeder were developed as a direct result of customer feedback. It represents a step forward in build quality in this scanner’s segment, effortlessly capturing up to 6,000 scans per day. Your productivity is maximised by the 60-sheet ADF that reliably feeds batches of mixed-sized document and media types: from passports and plastic cards to duplex A4, A3 (using folio) and long documents up to 3m in length.
Easy operation, consistent results
The imageFORMULA DR-C240 includes a wide range of high quality image processing capabilities. These include automatic page size and text direction detection, text enhancement, a deskew function and automatic colour detection. The user-friendly control panel lets operators scan with a press of a button – accelerating and simplifying scanning tasks
- Scanning speed A4 (single sided) - 44ppm
- Automatic document feeder - 60ppm
- from 3,500 to 6,000 scans/day
- Double-sided scanning
- USB connection
- Easy, intuitive scanning
- Enhanced image quality
GENERAL PRODUCT INFORMATION
Type
Desktop Type Sheet Fed Scanner
Scanning sensor unit
Optical resolution
Light source
Scanning side
Interface
Dimensions (WxDxH)
Trays Closed: 291 x 253 x 231 mm
Trays Opened: 291 x 603 x 363 mm
Weight
Power requirements
Power consumption
Scanning: 19W or less
Sleep Mode: 1.4W or less
Power Turned Off: 0.1W or less
Operating environment
10 - 32.5 °C
Humidity: 20 - 80% RH
Environmental compliance
SCANNING SPECIFICATIONS
DOCUMENT SPECIFICATIONS
Width
Length
Thickness
27 - 209g/m² (0.06 - 0.25mm)
Long document mode
Business card scanning
Size: 50.8 x 85mm or larger
Thickness: Less than 0.45 mm
Plastic card scanning
Size: 53.9 x 85.5mm
Thickness: 0.76mm (Embossed Card up to 1.4mm thick is supported)
Passport scanning
Up to 4mm thick (via carrier sheet)
Paper separation
Feeder capacity
SPECIAL FEATURES
Special Features
Automatic Page Size Detection, Deskew, 3-Dimensional Colour Correction, Colour Dropout (RGB), Colour Enhancement (RGB), Auto Colour Detection, Shadow Cropping, MultiStream, Adjustable gamma settings, Skip Blank Page, Folio Mode, Scan Area Setting, Batch Separation with white blank sheet or patchcode, Moiré Reduction, Prevent Bleed Through/Remove Background, Contrast Arrangement, Background Smoothing, Shadow Cropping, Auto Resolution Setting, Double Feed Release, Double Feed Detection (Ultrasonic Sensor, Length), Barcode/2D code recognition
BUNDLED SOFTWARE
Windows
ISIS / TWAIN Driver (Windows VISTA SP2 / 7 SP1 / 8 / 8.1 / Server 2008 R2 SP1 / Server 2012 R2)
CaptureOnTouch Pro
Kofax VRS
DR management Tool (by download only)
Mac
TWAIN Driver
CaptureOnTouch
Kofax VRS
OTHER OPTIONS
Accessories
A4 Flatbed Scanner Unit 102
A3 Flatbed Scanner Unit 202
NA10/WA10 Network Adapters
Carrying Case
